View 01 / 01DJI Focus Pro Motor.
What you get in the box
01Focus Pro Motor x 1
02Motor Rod Mount Kit x 1
03Focus Gear Strip x 1
04Multi-Camera Control Cable (USB-C, 30 cm) x 1
05FIZ Sticker x 1‌
0615mm Rod x 1
0710mm 1/4"-20 Screw x 2
50-day return policy⌄
  • Return within 50 days of purchase.
  • Full refund for unopened, sealed, unactivated items.
  • Opened products may still qualify if unused.
  • For orders over £100, we can arrange your return via DPD or in-person drop-off.
Next-day delivery — order before 3pm⌄
  • Order before 3pm Mon–Fri for next-working-day delivery (free over £99).
  • UK Saturday delivery available on orders placed before 3pm Friday.
  • After 3pm Friday — dispatched Monday.
  • Some UK regions may need 2–3 working days.
Discounted options with main purchase⌄
  • Bundle pricing on accessories, spares and training when bought together.
  • Reduced rates on add-ons selected at checkout.
  • Ask us for a tailored quote on multi-unit or fleet orders.
DJI · DJI Pro Modules

DJI Focus Pro Motor

SKU CP.RN.00000340.02

Enables accurate zoom control with modes including Power Zoom, Clear Image Zoom and External Focus Motor Zoom for precise footage. Compatible with the DJI RS 4 Pro and RS 4, as well as the RS 3 Pro, RS 3, Focus Pro Grip, Focus Pro Hand Unit, and Ronin 4D Flex.

3 in stock — UK warehouseNext-day if ordered before 3pm50-day returns
DJI Focus Pro Motor£119.00
Total today£119.00
Tax included in UKFree UK delivery
Pay with

Full specifications

DJI Focus Pro Motor
Specifications
Accessory Port1/4"-20 Mounting Hole / RSS Camera Control Port (USB-C) / NATO Expansion Port
BatteryModel: HB7-2450mAh-7.2 / Type: 18650 Li-ion 2S / Capacity: 2450 mAh / Energy: 17.64 Wh / Operating Time: 10 hours [1] / Charging Specification: 5 V/2 A / Charging Time: Approx. 2.5 hours [2] / Suggested Charging Temperature: 5° to 40° C (41° to 104° F)
ConnectionsBluetooth 5.1 / USB-C Charging Port
Ronin App RequirementsiOS 11.0 or above / Android 7.0 or above
Languages Supported by the TouchscreenEnglish, Simplified Chinese, Traditional Chinese, German, French, Korean, Japanese, Spanish, Portuguese (Brazil), Russian, Thai
Transmitter Power< 20 dBm (CE/SRRC/MIC), < 26 dBm (FCC)
Dimensions128×87×87 mm (L×W×H)
Weight555 g (without battery)
Static Power Consumption0.83 W
Operating Temperature-20° to 45° C (-4° to 113° F) (excluding battery temperature)
Ranging Points76,800
Sensing Range0.5-20 m
FOVWide-Angle Mode: 65° (horizontal), 40° (vertical), 76.1° (diagonal) / Telephoto Mode: 20° (horizontal), 20° (vertical), 28.3° (diagonal)
Frame Rate30fps
Equivalent Focal Length30 mm (wide-angle mode)
Ranging Accuracy±1% to 3% (affected by the distance)
Power ConsumptionAverage approx. 6.3 W, max 6.8 W
Input Voltage6.6-17.2 V
Main Body Dimensions68×25×57 mm (L×W×H)
Weight140 g
2.4GHz Transmitter Power (EIRP)< 20 dBm (CE/SRRC/MIC), < 26 dBm (FCC)
2.4GHz Transmission Distance160 m* / 100 m** / * Measured under FCC standard in an unobstructed environment free of interference. / ** Measured under CE/SRRC/MIC standards in an unobstructed environment free of interference.
Dimensions100×61×34 mm (L×W×H)
Weight123 g
Rod Diameter15 mm
Output Gear Teeth30
Output Gear Module0.8
