Aircraft
Take-off Weight<249 g
Dimensions (L x W x H)Folded: 145 x 90 x 62 mm / Unfolded: 171 x 245 x 62 mm / Unfolded (with propellers): 251 x 362 x 70 mm
Diagonal Length247 mm
Max Ascent Speed5 m/s (S Mode) / 3 m/s (N Mode) / 2 m/s (C Mode)
Max Descent Speed5 m/s (S Mode) / 3 m/s (N Mode) / 1.5 m/s (C Mode)
Max Speed (at Sea Level, no wind)16 m/s (S Mode) / 10 m/s (N Mode) / 6 m/s (C Mode) / /
Max Service Ceiling Above Sea Level4,000m
Max Flight Time34 mins (with Intelligent Flight Battery and measured while flying at 21.6 kph in windless conditions)
Max Hovering Time30 mins (with Intelligent Flight Battery, no wind)
Max Flight Distance / /18 km (with Intelligent Flight Battery and measured while flying at 43.2 kph in windless conditions)
Max Wind Speed Resistance10.7 m/s (Level 5)
Max Tilt AngleForward: 40°, Backward: 35° (S Mode) / 25° (N Mode) / 25° (C Mode)
Max Angular Velocity (by default)*130°/s (S Mode) / 75°/s (N Mode) / 30°/s (C Mode) / / *Can be adjusted between up to 250°/s in the app /
Operating Temperature-10°C to 40°C
Global Navigation Satellite System (GNSS)GPS + Galileo + BeiDou
Operation Frequency2.400-2.4835 GHz / 5.725-5.850 GHz /
Transmitter Power (EIRP)2.4 GHz: <20 dBm (CE/SRRC/MIC) / 5.8 GHz: <14 dBm (CE) /
Hovering Accuracy RangeVertical: / ±0.1 m (with vision positioning) / ±0.5 m (with GPS positioning) / / Horizontal: / ±0.3 m (with vision positioning) / ±0.5 m (with high-precision positioning system) /
Sensing System
ForwardPrecision Measurement Range: 0.39m-25 m / Effective Sensing Speed: Flight speed <10 m/s / FOV: Horizontal 106°, Vertical 90° /
BackwardPrecision Measurement Range: 0.15m-9m / Precise Hovering Range: 0.5m-12 m / Vision Sensor Hovering Range: 0.5m-30 m / Effective Sensing Speed: Flight speed <3 m/s / FOV: Forward/Backward 104.8°, Left/Right 87.6°
DownwardPrecision Measurement Range: 0.1m-8 m / Precise Hovering Range: 0.5m-12 m / Vision Sensor Hovering Range: 0.5m-30 m /
Auxiliary Bottom LightN/A
Operating EnvironmentDiffuse reflective surface with a clear pattern and reflectivity >20% (such as cement pavement) / Adequate lighting (lux >15, e.g. normal exposure environment with indoor fluorescent lamp) /
Gimbal
Mechanical RangeTilt: -135° to 80° / Roll: -135° to 45° / Pan: -30° to 30° /
Controllable RangeTilt: -90° to 60°
Stabilisation3-axis mechanical gimbal (tilt, roll, and pan)
Max Control Speed (tilt)100°/s
Angular Vibration Range±0.01°
Camera
Sensor1/1.3-inch CMOS / Effective Pixels: 48 MP /
LensFOV: 82.1° / Format Equivalent: 24 mm / Aperture: f/1.7 / Focus Range: 1 m to ∞ /
ISO RangeVideo: / 100-6400 (Auto) / 100-6400 (Manual) / / Photo: / 100-6400 (Auto) / 100-6400 (Manual) /
Shutter SpeedElectronic Shutter: 2-1/8000 s
Max Image Size4:3: / 8064×6048 (48 MP) / 4032×3024 (12 MP) / / 16:9: 4032×2268 (12 MP) /
Still Photography ModesSingle Shot / / Interval: / JPEG: 2/3/5/7/10/15/20/30/60 s / JPEG + RAW: 2/3/5/7/10/15/20/30/60 s / / Auto Exposure Bracketing (AEB): 3/5/7 bracketed frames at 2/3 EV Bias / / Panorama: Sphere, 180°, Wide-angle, and Vertical /
Photo FormatJPEG/DNG (RAW)
Video Resolution4K: 3840 x 2160@24/25/30/48/50/60fps / 2.7K: 2720 x 1530@24/25/30/48/50/60fps / FHD: 1920 x 1080@24/25/30/48/50/60fps / Slow Motion: 1920 x 1080@120fps /
Video FormatMP4/MOV (H.264/H.265)
Max Video Bitrate150 Mbps
Zoom Range4K: 2x / 2.7K: 3x / FHD: 4x /
QuickShot ModesDronie, Helix, Rocket, Circle, Boomerang, and Asteroid
Colour ProfilesNormal / D-Cinelike /
Supported File SystemFAT32 (≤32 GB) / exFAT (>32 GB) /
Video Transmission
Video Transmission SystemDJI O3
Live View Quality1080p/30fps
Operation Frequency2.400-2.4835 GHz / 5.725-5.850 GHz / (Due to local policy and regulation restrictions, the 5.8 GHz frequency band is currently banned in certain countries, including but not limited to Japan, Russia, Israel, Ukraine, and Kazakhstan. Please use the 2.4 GHz frequency band when operating in these locations. Always check local rules and regulations before use, as they may change over time). /
Transmitter Power (EIRP)2.4 GHz: <26 dBm (FCC), <20 dBm (CE/SRRC/MIC) / 5.8 GHz: <26 dBm (FCC/SRRC), <14 dBm (CE)
Communication Bandwidth1.4MHz/3MHz/10MHz/20MHz/40MHz
Latency (depending on environmental conditions and mobile device)Aircraft + Remote Controller: Approx. 120 ms
Max Video BitrateAircraft + Remote Controller: 18 Mbps
Max Download BitrateDJI O3: / RC-N1 Remote Controller and DJI RC: 5.5 MB/s / / Wi-Fi 5: / Max 30 MB/s /
Antennas4 antennas, 1T2R
Audio TransmissionN/A
Wi-Fi
Protocol802.11 a/b/g/n/ac
Transmitter Power (EIRP)2.400-2.4835 GHz: <19 dBm (FCC/CE/SRRC/MIC) / 5.725-5.850 GHz: <20 dBm (FCC/SRRC), <14 dBm (CE)
Bluetooth
ProtocolBluetooth 5.2
Transmitter Power (EIRP)2.400-2.4835 GHz: <8 dBm
Intelligent Flight Battery
Capacity2453mAh
Weight80.5g
Voltage7.38V
Charging Voltage Limit8.5V
Battery TypeLi-ion
Energy18.1Wh
Max Charging Power37W
Charging Time64 mins (with DJI 30W USB-C charger)
Charging Temperature Range5°C to 40°C (41°F to 104°F)
Recommended ChargerDJI 30W USB-C Charger or other USB Power Delivery chargers /
Memory Cards
Supported Memory CardsUHS-I Speed Class 3 or above is required. A list of recommended microSD cards can be found below.
Recommended microSD CardsSanDisk Extreme 64GB V30 A1 microSDXC / SanDisk Extreme 128GB V30 A2 microSDXC / SanDisk Extreme 256GB V30 A2 microSDXC / SanDisk Extreme 512GB V30 A2 microSDXC / SanDisk Extreme Pro 64GB V30 A2 microSDXC / SanDisk Extreme Pro 256GB V30 A2 microSDXC / SanDisk Extreme Pro 400GB V30 A2 microSDXC / SanDisk High Endurance 64GB V30 microSDXC / SanDisk High Endurance 256GB V30 microSDXC / SanDisk Max Endurance 32GB V30 microSDHC / SanDisk Max Endurance 128GB V30 microSDXC / SanDisk Max Endurance 256GB V30 microSDXC / Kingston Canvas Go! Plus 64GB V30 A2 microSDXC / Kingston Canvas Go! Plus 256GB V30 A2 microSDXC / Lexar High Endurance 64GB V30 microSDXC / Lexar High Endurance 128GB V30 microSDXC / Lexar 667x 64GB V30 A1 microSDXC / Lexar 633x 256GB V30 A1 microSDXC / Lexar 1066x 64GB V30 A2 microSDXC / Lexar 1066x 128GB V30 A2 microSDXC / Lexar 1066x 256GB V30 A2 microSDXC / Samsung Pro Plus 128GB V30 A2 microSDXC / Samsung EVO Plus 512GB microSDXC /
App
Mobile Device AppDJI Fly
Required Operating SystemiOS v11.0 or later / Android v6.0 or later /
DJI RC
ModelRM330
Video Transmission SystemDJI O3
Transmitter Power (EIRP)2.400-2.4835 GHz: <20 dBm (CE) / 5.725-5.850 GHz: <14 dBm (CE) /
Storage CapacityDJI RC's storage capacity can be increased by using a microSD card. Users can store images and videos on the card and export them to a computer or other devices.
Video Output PortNo
Max Battery LifeApprox 4 hours
Operating Temperature-10°C to 40°C (14°F to 104°F)
Recommended microSD CardsSanDisk Ultra A1 U1 16GB / SanDisk Extreme U3 16GB / SanDisk Ultra A1 U1 32GB / SanDisk Extreme A1 U3 32GB / Kingston A2 V30 U3 64GB / SanDisk Extreme A2 V30 U3 64GB / SanDisk Extreme Pro A2 V30 U3 64GB / SanDisk High Endurance V30 U3 64GB / Kingston A2 V30 U3 128GB / SanDisk Extreme A2 V30 U3 128GB / SanDisk Ultra A1 U1 200GB / Kingston A2 V30 U3 256GB / SanDisk Extreme A2 V30 U3 256GB / SanDisk Extreme PRO A2 V30 U3 256GB / SanDisk Extreme A2 V30 U3 512GB /
WiFi
Protocol802.11 a/b/g/n
Transmitter Power (EIRP)2.400-2.4835 GHz: <20 dBm (CE/SRRC/MIC) / 5.150-5.250 GHz: <23 dBm (FCC/CE/SRRC/MIC) / 5.725-5.850 GHz: <14 dBm (CE) /
Bluetooth
ProtocolBluetooth 4.2
Transmitter Power (EIRP)2.400-2.4835 GHz: <10 dBm
