Aircraft
Takeoff WeightStandard aircraft weight (including the Intelligent Flight Battery, propellers, and a microSD card). The actual product weight may vary due to differences in batch materials and external factors. Registration is not required in some countries and regions. Always check local laws and regulations before use. With the Intelligent Flight Battery Plus*, the aircraft will weigh more than 249 g. Always check and strictly abide by local laws and regulations before flying. / / * The Intelligent Flight Battery Plus is not sold in Europe.
DimensionsFolded (without propellers): 148×94×64 mm (L×W×H) / / Unfolded (with propellers): 298×373×101 mm (L×W×H)
Max Ascent Speed5 m/s (S Mode) / / 5 m/s (N Mode) / / 3 m/s (C Mode)
Max Descent Speed5 m/s (S Mode) / / 5 m/s (N Mode) / / 3 m/s (C Mode)
Max Horizontal Speed (at sea level, no wind)16 m/s (S Mode) / / 12 m/s (N Mode) / / 12 m/s (C Mode) / / The max horizontal speed is subject to dynamic local restrictions. Always abide by local laws and regulations when flying.
Max Takeoff AltitudeWith DJI Mini 4 Pro Intelligent Flight Battery: 4000 m / / With DJI Mini 3 Series Intelligent Flight Battery Plus*: 3000 m / / Increase in aircraft weight can affect flight propulsion. When the aircraft is using the Intelligent Flight Battery Plus, do not mount additional payloads like a propeller guard or third-party accessories to avoid diminished propulsion. / / * The Intelligent Flight Battery Plus is not sold in Europe.
Max Flight Time34 minutes (with Intelligent Flight Battery) / / 45 minutes (with Intelligent Flight Battery Plus)* / / Measured in a controlled test environment. Specific test conditions are as follows: flying forward at a constant speed of 21.6 kph in a windless laboratory environment at 20 meters above sea level, in photo mode (without photo taking operation during flight), with Obstacle Avoidance Action set to Off, and from 100% battery level until 0%. Results may vary depending on the environment, actual use, and firmware version. / / * The Intelligent Flight Battery Plus is not sold in Europe.
Max Hovering Time30 minutes (with Intelligent Flight Battery) / / 39 minutes (with Intelligent Flight Battery Plus)* / / Measured in a controlled test environment. Specific test conditions are as follows: hovering in a windless laboratory environment at 20 meters above sea level, in photo mode (without photo taking operation during flight), with Obstacle Avoidance Action set to Off, and from 100% battery level until 0%. Results may vary depending on the environment, actual use, and firmware version. / / * The Intelligent Flight Battery Plus is not sold in Europe.
Max Flight Distance18 km (with Intelligent Flight Battery and measured while flying at 40.7 kph in a windless environment at 20 meters above sea level) / / 25 km (with Intelligent Flight Battery Plus* and measured while flying at 44.3 kph in a windless environment at 20 meters above sea level) / / * The Intelligent Flight Battery Plus is not sold in Europe.
Max Wind Speed Resistance10.7 m/s
Max Pitch Angle35°
Operating Temperature-10° to 40° C (14° to 104° F)
Global Navigation Satellite SystemGPS + Galileo + BeiDou
Hovering Accuracy Range (windless or breezy)Vertical: / / ±0.1 m (with vision positioning) / / ±0.5 m (with GNSS positioning) / / Horizontal: / / ±0.1 m (with vision positioning) / / ±0.5 m (with GNSS positioning)
Internal Storage2 GB
Camera
Image Sensor1/1.3-inch CMOS, Effective Pixels: 48 MP
LensFOV: 82.1° / / Format Equivalent: 24 mm / / Aperture: f/1.7 / / Focus: 1 m to ∞
ISO RangeVideo / / Normal and Slow Motion: / / 100-6400 (Normal) / / 100-1600 (D-Log M) / / 100-1600 (HLG) / / / / Night: / / 100-12800 (Normal) / / / / Photo / / 12 MP: 100-6400 / / 48 MP: 100-3200
Shutter Speed12MP Photo: 1/16000-2 s (2.5-8 s for simulated long exposure) / / 48MP Photo: 1/8000-2 s
Max Image Size8064×6048
Still Photography ModesSingle Shot: 12 MP and 48 MP / / Burst Shooting: / / 12 MP, 3/5/7 frames / / 48 MP, 3 frames / / Automatic Exposure Bracketing (AEB): / / 12 MP, 3/5/7 frames at 0.7 EV step / / 48 MP, 3 frames at 0.7 EV step / / Timed: / / 12 MP, 2/3/5/7/10/15/20/30/60 s / / 48 MP, 5/7/10/15/20/30/60 s
Photo FormatJPEG/DNG (RAW)
Video ResolutionH.264/H.265 / / 4K: 3840×2160@24/25/30/48/50/60/100*fps / / FHD: 1920×1080@24/25/30/48/50/60/100*/200*fps / / * Recording frame rates. The corresponding video plays as slow-motion video. 4K/100fps and HLG/D-Log M only support H.265 coding.
Video FormatMP4 (MPEG-4 AVC/H.264, HEVC/H.265)
Max Video BitrateH.264/H.265: 150 Mbps
Supported File SystemexFAT
Color Mode and Sampling MethodNormal: / / 8-bit 4:2:0 (H.264/H.265) / / HLG/D-Log M: / / 10-bit 4:2:0 (H.265)
Digital Zoom12MP Photo: 1-2x / / 4K: 1-3x / / FHD: 1-4x
Stabilization3-axis mechanical gimbal (tilt, roll, pan)
Mechanical RangeTilt: -135° to 80° / / Roll: -135° to 45° / / Pan: -30° to 30°
Controllable RangeTilt: -90° to 60° / / Roll: -90° or 0°
Max Control Speed (tilt)100°/s
Angular Vibration Range±0.01°
Sensing
Sensing TypeOmnidirectional binocular vision system, supplemented with a 3D infrared sensor at the bottom of the aircraft
ForwardMeasurement Range: 0.5-18 m / / Detection Range: 0.5-200 m / / Effective Sensing Speed: Flight Speed ≤ 12 m/s / / FOV: Horizontal 90°, Vertical 72°
BackwardMeasurement Range: 0.5-15 m / / Effective Sensing Speed: Flight Speed ≤ 12 m/s / / FOV: Horizontal 90°, Vertical 72°
LateralMeasurement Range: 0.5-12 m / / Effective Sensing Speed: Flight Speed ≤ 12 m/s / / FOV: Horizontal 90°, Vertical 72°
UpwardMeasurement Range: 0.5-15 m / / Effective Sensing Speed: Flight Speed ≤ 5 m/s / / FOV: Front and Back 72°, Left and Right 90°
DownwardMeasurement Range: 0.3-12 m / / Effective Sensing Speed: Flight Speed ≤ 5 m/s / / FOV: Front and Back 106°, Left and Right 90°
Operating EnvironmentForward, Backward, Left, Right, and Upward: / / Surfaces with discernible patterns and adequate lighting (lux > 15) / / Downward: / / Surfaces with discernible patterns, diffuse reflectivity > 20% (e.g. walls, trees, people), and adequate lighting (lux > 15)
3D Infrared SensorMeasurement Range: 0.1-8 m (reflectivity > 10%) / / FOV: Front and Back 60°, Left and Right 60°
Video Transmission
Video Transmission SystemO4
Live View QualityRemote Controller: / / Up to 1080p/60fps (available when the aircraft is flying in Photo or Video mode) / / Up to 1080p/30fps (available when the aircraft is flying in Video mode) / / Up to 1080p/24fps (available when the aircraft is in standby mode on the ground)
Operating Frequency2.4000-2.4835 GHz / / 5.170-5.250 GHz / / 5.725-5.850 GHz / / 5.170-5.250 GHz can be used only in countries and regions where permitted by local laws and regulations.
Transmitter Power (EIRP)2.4 GHz: / / < 33 dBm (FCC) / / < 20 dBm (CE/SRRC/MIC) / / / / 5.1 GHz: / / < 23 dBm (CE) / / / / 5.8 GHz: / / < 33 dBm (FCC) / / < 30 dBm (SRRC) / / < 14 dBm (CE)
Max Transmission Distance (unobstructed, free of interference)FCC: 20 km / / CE: 10 km / / SRRC: 10 km / / MIC: 10 km / / Measured in an unobstructed outdoor environment free of interference. The above data shows the farthest communication range for one-way, non-return flights under each standard. Always pay attention to RTH reminders in the DJI Fly app during your flight.
Max Transmission Distance (unobstructed, with interference)Strong Interference: urban landscape, approx. 1.5-4 km / / Medium Interference: suburban landscape, approx. 4-10 km / / Low Interference: suburb/seaside, approx. 10-20 km / / Data tested under FCC standard in unobstructed environments with typical interference. Used for reference purposes only and provides no guarantee for actual transmission distance.
Max Transmission Distance (obstructed, with interference)Low Interference and Obstructed by Buildings: approx. 0-0.5 km / / Low Interference and Obstructed by Trees: approx. 0.5-3 km / / Data tested under FCC standard in obstructed environments with typical low interference. Used for reference purposes only and provides no guarantee for actual transmission distance.
Max Download SpeedO4: / / 10 MB/s (with DJI RC-N2) / / 10 MB/s (with DJI RC 2) / / Wi-Fi 5: 30 MB/s* / / * Measured in a laboratory environment with little interference in countries/regions that support both 2.4 GHz and 5.8 GHz, with footage saved to the internal storage. Download speeds may vary depending on the actual conditions.
Lowest LatencyAircraft + Remote Controller: approx. 120 ms / / Depending on the actual environment and mobile device.
Antenna4 antennas, 2T4R
Battery
Compatible BatteryDJI Mini 4 Pro Intelligent Flight Battery, DJI Mini 3 Series Intelligent Flight Battery Plus* / / * The Intelligent Flight Battery Plus is not sold in Europe.
CapacityIntelligent Flight Battery: 2590 mAh / / Intelligent Flight Battery Plus*: 3850 mAh / / * The Intelligent Flight Battery Plus is not sold in Europe.
WeightIntelligent Flight Battery: approx. 77.9 g / / Intelligent Flight Battery Plus*: approx. 121 g / / * The Intelligent Flight Battery Plus is not sold in Europe.
Nominal VoltageIntelligent Flight Battery: 7.32 V / / Intelligent Flight Battery Plus*: 7.38 V / / * The Intelligent Flight Battery Plus is not sold in Europe.
Max Charging VoltageIntelligent Flight Battery: 8.6 V / / Intelligent Flight Battery Plus*: 8.5 V / / * The Intelligent Flight Battery Plus is not sold in Europe.
TypeLi-ion
EnergyIntelligent Flight Battery: 18.96 Wh / / Intelligent Flight Battery Plus*: 28.4 Wh / / * The Intelligent Flight Battery Plus is not sold in Europe.
Charging Temperature5° to 40° C (41° to 104° F)
Charging TimeIntelligent Flight Battery: / / 70 minutes (with the DJI 30W USB-C Charger and the battery mounted to the aircraft) / / 58 minutes (with the DJI 30W USB-C Charger and the battery inserted into the Two-Way Charging Hub) / / / / Intelligent Flight Battery Plus*: / / 101 minutes (with the DJI 30W USB-C Charger and the battery mounted to the aircraft) / / 78 minutes (with the DJI 30W USB-C Charger and the battery inserted into the Two-Way Charging Hub) / / * The Intelligent Flight Battery Plus is not sold in Europe.
Charger
Recommended ChargerDJI 30W USB-C Charger or other USB Power Delivery chargers (30 W)* / / * When you charge the battery mounted to the aircraft or inserted into the Two-Way Charging Hub, the maximum charging power supported is 30 W.
Charging Hub
Input5 V, 3 A / / 9 V, 3 A / / 12 V, 3 A
OutputUSB-A: Max Voltage: 5 V; Max Current: 2 A
Charging TypeThree batteries charged in sequence.
CompatibilityDJI Mini 4 Pro Intelligent Flight Battery, DJI Mini 3 Series Intelligent Flight Battery/Intelligent Flight Battery Plus* / * The Intelligent Flight Battery Plus is not sold in Europe.
Storage
Recommended microSD CardsSanDisk Extreme PRO 32GB V30 U3 A1 microSDHC / / Lexar 1066x 64GB V30 U3 A2 microSDXC / / Lexar 1066x 128GB V30 U3 A2 microSDXC / / Lexar 1066x 256GB V30 U3 A2 microSDXC / / Lexar 1066x 512GB V30 U3 A2 microSDXC / / Kingston Canvas GO! Plus 64GB V30 U3 A2 microSDXC / / Kingston Canvas GO! Plus 128GB V30 U3 A2 microSDXC / / Kingston Canvas React Plus 64GB V90 U3 A1 microSDXC / / Kingston Canvas React Plus 128GB V90 U3 A1 microSDXC / / Kingston Canvas React Plus 256GB V90 U3 A1 microSDXC / / Samsung EVO Plus 512GB V30 U3 A2 microSDXC
